Three Phase Grid-tied Inverter 50kW with AFCI(optional)

Name: Three Phase Grid-tied Inverter 50kW with AFCI(optional)
SKU: GT3-50KQ1R11001
Price: 3400.00 EUR
Availability: InStock

SKU GT3-50KQ1R11001 Categories Grid-tied Inverter, Inverters, Three Phase

Price:

€3,400.00

100 in stock

LIVOLTEK GT3-30 kW PV inverters are widely used in residential, commercial and industrial project.The maximum input current of each MPPT is 40A, also compatible with 600W+ PV modules in the global markets. Combined with 6 string of DC input and precise algorithm, it’s the ideal option for rooftop photovoltaic systems with complex orientations and various components. Built-in PID recovery function , so as to maximize continuous long-term benefits for end-users.

24/7 live monitoring
String current up to 20A
Night SVG function
Built-in PID recovery function

Phase	Three Phase
Power	50KW
Model	GT3-50KQ1
Max. PV Input Power	75000Wp
Max. PV Input Voltage	1100V
Start-up Input Voltage	180V
Nominal Input Voltage	620V
MPPT Voltage Range	180V-1000V
Max. PV Input Current	40A/40A/40A/40A
Max.Short Circuit current	52A/52A/52A/52A
No. of MPPTs	4
No. of Strings per MPP Tackers	2/2/2/2
Nominal AC Power	50000W
Max. Apparent Power	55000VA
Rated AC Grid Output Current	76.0A
Max. AC Output Current	83.6A
Rated AC Grid Voltage	3/N/PE , 3/PE , 380V/400V
AC Grid Voltage Range[1]	310V~480V
Rated Grid Frequency	50Hz/60Hz
Grid Frequency Range[2]	45Hz-55Hz/55Hz-65Hz
Power Factor	> 0.99 Rated Power (Adjustable 0.8 Leading – 0.8Lagging)
THDi, Rated Power[%]	<3%
Max. Efficiency	98.50%
Euro Efficiency	98.30%
Surge Arrester	Type II
AC Short Circuit Protection	Support
Anti-islanding Protection	Support
Shade Fix Function	Support
Integrated PID recovery	Support
AC Auxiliary Power Supply (APS)	Support
Residual Current Monitoring Unit	Support
Integrated AFCI (Arc-Fault Circuit Protection)	Support
Dimension (WHD)	481613251mm
Weight	47kg
Protection Degree	IP65
Cooling	Fan
Operating Temperature Range	-30°C ~ +60°C (Derating at 45°C)
Night Self Consumption	<3W
Display	LED+APP
Communication	RS485 (Meter/GEN/DRM) , Wi-Fi
Certifications and Standards	.
Grid Regulation	IEC61727 , IEC62116，EN50549
Safety/EMC	IEC62109-1/-2; EN61000-6-1/2/3/4
Standard Warranty	5 Years/10 Years (Optional)
