€1,700.00
100 in stock
The LIVOLTEK 3 kW single phase hybrid inverter is an ideal choice for new photovoltaic systems, enhancing energy storage and utilization for residential and small business applications.
| Power |
6KW |
|---|---|
| Phase |
Single Phase |
| Model |
Hyper-6000 |
| Max. PV Input Power |
7500Wp |
| Max. PV Input Voltage |
600V |
| Nominal Input Voltage |
360V |
| MPPT Voltage Range |
125~550V |
| No. of MPPTs/Strings per MPPT |
2 / 1 |
| Max. PV Current |
14/14A |
| Max. Short Circuit Current |
17.5/17.5A |
| Nominal AC Power |
6000W |
| Max. Apparent Output Power |
6000VA |
| Nominal AC Voltage |
220V/230V/240V |
| Nominal AC Voltage Range |
186~290V |
| AC Frequency |
50Hz/60Hz |
| Max. AC Current |
26.1A |
| THDi,Rated Power[%] |
<3% |
| Power Factor |
~1 (Adjustable from 0.8 Leading to 0.8 Lagging) |
| Nominal EPS Power |
6000W |
| EPS Peak Power |
1.1 x Pnom , 60 sec; 1.5 x Pnom , 1 sec |
| Nominal Output Voltage |
220V/230V |
| Nominal Frequency |
Nominal Frequency |
| Nominal Output Current |
26.1A |
| THDv,Rated Power[%] |
< 3% |
| Battery Type |
Lithium |
| Battery Voltage |
40~60V |
| Max. Charge/Discharge Current |
125A |
| Communication with BMS |
CAN |
| Max. Efficiency |
97.8% |
| Euro Efficiency |
97.4% |
| Dimension (W*H*D) |
415*625*155mm |
| Weight |
30kg |
| Mounting Method |
Wall-mounting Bracket |
| Protection Rating |
IP65 |
| Cooling |
Natural Convection |
| Operating Temperature Range |
-25℃~+60℃ (>45℃ Derating) |
| Display |
LED & APP |
| Communication |
Wi-Fi/DRM/CAN/RS485 |
| Standard Warranty |
5 Years |
| Remarks: The range of output Voltage and frequency may vary depending upon different grid codes. |
. |
